Smart Function ? Deep learning-based motion detection 2.0 Compression and Recording ? H.265 Pro+ video compression improves encoding efficiency, and reduces data storage costs ? Support 1080p Lite of all channels. When 1080p Lite is on, the image effect is similar with 1080p Storage and Playback ? 2 SATA interfaces (up to 10 TB capacity) ? Smart search for efficient playback Network & Ethernet Access ? Hik-Connect & DDNS (Dynamic Domain Name System) for easy network management
? Specification Motion Detection 2.0 Human/Vehicle Analysis Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported; Recording Video Compression H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 Encoding Resolution 1080p lite/720p/720p lite/WD1/4CIF/VGA/CIF Frame Rate Main stream: For 1080p stream access: 1080p lite/720p lite/WD1/4CIF/VGA@15fps; CIF@25fps For 720p stream access: 720p/WD1/4CIF/VGA@15fps; CIF@25fps For standard definition stream access: WD1/4CIF/VGA/CIF@25fps Sub-stream: CIF/QVGA@15fps Video Bitrate 32 Kbps to 4 Mbps Dual-stream Nonsupport Stream Type Video, Video & Audio Audio Compression G.711u Audio Bitrate 64 Kbps Video and Audio IP Video Input 2-ch (up to 18-ch) Up to 5 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras Analog Video Input 32-ch BNC interface (1.0 Vp-p, 75 ?), supporting coaxitron connection HDTVI Input 1080p25, 1080p30, 720p25, 720p30 AHD Input 1080p25, 1080p30, 720p25, 720p30 HDCVI Input 1080p25, 1080p30, 720p25, 720p30 CVBS Input PAL/NTSC HDMI Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz VGA Output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz CVBS Output 1-ch, BNC (1.0 Vp-p, 75 ?) Audio Input 1-ch, RCA (2.0 Vp-p, 1 K?) 32-ch via coaxial cable Audio Output 1-ch, RCA (Linear, 1 K?) Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 K?) (using the first audio input) Synchronous Playback 16-ch Network Remote Connection 128 Total Bandwidth 128 Mbps Network Protocol TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, EHome Network Interface 1, RJ45 10M/100M/1000M self-adaptive Ethernet interface Wi-Fi Connectable to Wi-Fi network by Wi-Fi dongle througH
