• 2 MP high-performance CMOS
• Ultra low light
• 1920 × 1080 resolution
• 2.8 mm, 3.6 mm, 6 mm fixed lens
• EXIR 2.0, smart IR, up to 30 m IR distance
• OSD menu, 3D DNR, 120 dB true WDR, day/night switch
• 4 in 1 video output (switchable TVI/AHD/CVI/CVBS)
• IP67
• Up the coax (HIKVISION-C)

General

• Operating Conditions : -40 °C to 60 °C (-40 °F to 140 °F), Humidity: 90% or less (non-condensation)
• Power Supply : 12 VDC ±25%
• Power Consumption : Max. 4.6 W
• Protection Level : IP67
• Material : Plastic
• IR Range : Up to 30 m
• Dimensions : 158 mm × 61 mm × 58 mm (6.42" × 2.40" × 2.28")
• Weight : Approx. 177 g (0.39 lb.)

Camera Specification

• Image Sensor : 2.0 megapixel progressive scan CMOS
• Signal System : PAL/NTSC
• Video Frame Rate : PAL: 1080p@25fps, NTSC: 1080p@30fps
• Resolution : 1920 (H) ×1080 (V)
• Min. Illumination : 0.005 Lux@(F1.2, AGC ON), 0 Lux with IR
• Shutter Time : PAL: 1/25 s to 1/50, 000 s, NTSC: 1/30 s to 1/50, 000 s
• Lens : 2.8 mm, 3.6 mm, 6 mm
• Horizontal Field of View : 106°(2.8 mm), 82°(3.6 mm), 51°(6 mm)
• Lens Mount : M12
• Day & Night : IR cut filter
• Angle Adjustment : Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
• Synchronization : Internal synchronization
• WDR (Wide Dynamic Range) : ≥ 120 dB

Menu

• AGC : High/Medium/Low
• D/N Mode : Auto/Color/BW (Black and White)
• Image Mode : STD/HIGH-SAT
• BLC (Backlight Compensation) : Yes
• WDR : Yes
• 3D DNR Level : 1 to 9
• Language : English
• Functions : Brightness, Sharpness, 3D DNR, Mirror, Smart IR

Interface

• Video Output : 1 HD analog output
• Switch Button : TVI/AHD/CVI/CVBS
