Camera Specification

• Image Sensor : 1/2.8" Progressive Scan CMOS
• Min. Illumination : Color: 0.001 Lux @ (F1.0, AGC ON)
• Shutter Speed : 1/3 s to 1/100,000 s
• Slow Shutter : Yes
• Angle Adjustment : Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
• P/N : P/N
• Wide Dynamic Range : Digital WDR

Lens

• Lens Type & FOV : 2.8 mm, horizontal FOV 107°, vertical FOV 56°, diagonal FOV 127°, 4 mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 99°
• Aperture : F1.0
• Lens Mount : M12
• Aperture Type : Fixed
• Depth of Focus 2.8 mm: 1.7 m to ∞, 4 mm: 2.1 m to ∞

Illuminator

• Smart Supplement Light : Yes
• Supplement Light : White
• White Light Range : Up to 30 m

Video

• Main Stream : 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720), 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
• Sub Stream : 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240), 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
• Video Compression : Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG
• Video Bit Rate : 32 Kbps to 8 Mbps
• H.264 Type : BaseLine Profile/Main Profile/High Profile
• H.265 Type : Main Profile
• Region of Interest (ROI) : 1 fixed region for main stream

Network

• Simultaneous Live View : Up to 6 channels
• API : ONVIF (PROFILE S, PROFILE G), ISAPI, SDK
• Protocols : TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, UDP, Bonjour, SSL/TLS
• User/Host : Up to 32 users. 3 user levels: administrator, operator and user
• Security : Password protection, complicated password, HTTPS encryption, IP address filter, security audit log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for ONVIF
• Client : iVMS-4200, Hik-Connect, Hik-Central
• Web Browser : Plug-in required live view: IE8, IE9, IE10, IE11, Local service: Chrome 57.0+, Firefox 52.0+


• Day/Night Switch : Day, Night, Auto, Schedule
• Image Enhancement : BLC, HLC, 3D DNR
• Image Settings : Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser

Interface

• Communication Interface : 1 RJ45 10M/100M self-adaptive Ethernet port
• Intelligent (Traditional Algorithm) : Basic Event Motion detection, exception (illegal login)
