Features and Functions

• Professional and Reliable
• Dual-OS design to ensure high reliability of system running
• ANR technology to enhance the storage reliability when the network is disconnected

HD Input

• H.265/H.264/H.264+ video formats
• Connectable to the third-party network cameras
• 4 IP cameras can be connected
• Recording at up to 8 MP resolution
• Supports live view, storage, and playback of the connected camera at up to 8 MP resolution

HD Output

• HDMI/VGA outputs provided
• HDMI Video output at up to 4K (3840 × 2160) resolution

HD Storage

• 1 SATA interfaces connectable for recording and backup
• Storage space effectively saved by 50% to 70% with the use of H.264+ decoding format

HD Transmission

• 1 self-adaptive 10M/100Mbps network interface
• 4 independent PoE network interfaces are provided

Various Applications

• Centralized management of IP cameras, including configuration, information import/export, real-time information display, two-way audio, upgrade, etc.
• Connectable to smart IP cameras from Hikvision and the recording, playing back, and backing up of VCA alarms can be realized
• VCA detection alarm is supported
• Instant playback for assigned channel during multi-channel display mode
• Smart search for the selected area in the video; and smart playback to improve the playback efficiency

Video/Audio input

• IP video input : 4-ch
• Incoming bandwidth : 40 Mbps
• Outgoing bandwidth : 80 Mbps

Video/Audio output

• HDMI/VGA output resolution : HDMI:4K (3840 × 2160)/30Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz,
• 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz, VGA:1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• Audio output : 1-ch, RCA (Linear, 1 KΩ)

Decoding

• Decoding format : H.265/H.264/H.264+
• Recording resolution : 8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
• Synchronous playback : 4-ch
• Capability : 4-ch @ 1080p

Hard disk

• SATA : 1 SATA interface for 1HDD
• Capacity : Up to 6TB capacity for each disk

Network management

• Network protocols : TCP/IP, DHCP, HIK Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
• External interface : Two-way audio 1-ch, RCA (2.0 Vp-p, 1kΩ)
• Network interface : 1 RJ-45 100 Mbps full-duplex Ethernet interface
• USB interface : Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0

POE Interface

• Interface : 4 RJ-45 100 Mbps full-duplex Ethernet interfaces
• Power : ≤ 40 W
• Supported standard : IEEE 802.3 af/at

General

• Power supply : 48 VDC
• Power : ≤ 65 W
• Consumption(without hard disk) : ≤ 10 W (without enabling PoE)
• Working temperature : -10 to +55° C (14 to 131° F)
• Working humidity : 10 to 90 %
• Chassis : 1U chassis
• Dimensions(W × D × H) : 315 × 240 × 48 mm (12.4" × 9.4" × 1.9")
• Weight(without hard disk) : 1 kg (2.2 lb)
